Styles and Colours

Custom Fascia and Spouting

Gutter styles

Styles

Spouting and Gutters

The Box Gutter

Box Gutter
125mm, 175mm & 300mm
Gutter sizes are designed to perform where heavy rainfall may occur. A higher face prevents unsightly views of the end of the roofing sheet, particularly on higher ribbed profiles.

Quarter Round Spouting

Quater Round Spouting
Quarter Round Spouting maintains its traditional appeal, and provides simplicity and classic lines for use in most residential applications. Supplied with internal or external brackets.

1/2 Round Spouting

Half Round Spouting
1/2 Round 150mm
Well proven and recognised as an aesthetically pleasing spouting product, the ½ Round will certainly enhance the overall appeal of your home.

Old Gothic Spouting

Old Gothic spouting
125mm and 150mm
Old Gothic, which is available in two sizes, is reminiscent of the spouting types used on colonial homes. Old Gothic spouting is supplied with internal or external brackets.
Cross Section mm
(SQ)
125mm Half Round
6150
150mm Half Round
8700
1/4 Round
6300
125mm O/G
5800
150mm O/G
9000
125 Box Gutter
7500
175mm box gutter
20100
Quarter Round Spouting

Fascia Panelling

Versatile Fascia Panels in Various Sizes to Complement Any Roof Type

Fascia panelling can be used in conjunction with a wide number of roof types. Fascia panels work by incorporating a simple attachment system that allows removal and re-installation without disturbing the main roof material.
NOTE: Timber fascia panels which are a pre-painted finished product.
Our quality fascia panelling are available in the following sizes:

Standard Fascia Panels:

135mm
150mm
190mm (also available in wood grain)

Timber Fascia Panels:

165mm
195mm
Fascia panelling examples

Downpipes

Downpipe Diameter

Downpipe examples
100mm | 80 mm | 65mm
Our standard downpipes come in sizes of 65mm, 80mm, 100mm, and 150mm, and are provided in various lengths to meet your needs.

We can also create custom downpipes in square or rectangular shapes, or design something unique for your specific application.

We offer and install downpipes in materials such as ColorCote, copper, aluminum, titanium zinc, stainless steel, and PVC. We strive to ensure you get the right material and color to complement your home.
Roof Pitch Specifications
Roof pitch (degrees)
0 – 25
26 – 35
36 – 45
46 – 55
65mm Round
60
50
40
35
80mm Round
100
80
70
60
100mm Round
155
130
110
90
Downpipe example

Rainwater Heads

Rainwater head
At Custom Fascia and Spouting, we provide a variety of rainwater heads in both standard and custom designs.

Our rainwater heads are available in ColorCote, copper, aluminum, titanium zinc, and stainless steel. Our rainwater systems are offered in aluminum, titanium zinc, and stainless steel for enhanced durability and strength.

Contact us to see what we can do for you.

Colours

With 40 shades to choose from, our color range is perfect for any project. Whether you're re-roofing a villa on a heritage-protected, tree-lined avenue or building a modern, architecturally designed home, we have the perfect colors to suit your needs and complement your home's style. Our finishes range from bold high gloss to low gloss options that meet council reflectivity requirements and blend subtly with your environment.
Due to the many variations in computer screens and web browsers, the colours you see may not be exactly the same as ColorCote or Resene products. It is recommended that you order a printed copy of the ColorCote colour chart or sample first, before placing the order for your new roof. You can do this here.

White and Creams

Threadbow White
Pacific White
Off White
Pacific Cloud
Titania
Bone White
Smooth Cream

Greys

Gull Grey
Sandstone Grey
Grey Flannel
Thunder Grey
Grey Friars
Seabird
Slate
Windsor Grey
Horoeka
Black

Blues and Greens

Nimbus
New Denim Blue
Storm Blue
Slate Blue
Smokey
Mist Green
Rivergum
Forest Fern
Permanent Green
Karaka

Reds and Browns

Desert Sand
Terracotta
Pioneer Red
Scoria
Pebble
Lichen
Mudstone
Lignite
Weathered Copper
Ironsand

Metalics

Colours in this range may vary slightly between production runs. It is imperative that the entire quantity required for each project is purchased as a single order. Metallic colours also incur a production surcharge.

Due to the composition of this paint film, metallic colours are not recommended for use in coastal environments.
Metallic Silver
Metallic Gunmetal

Brights

These colours are not available with ceramic pigmentation, therefore the level of colour retention is not as high as the rest of our range. There is no colour fade warranty given on these colours.
Lazerite Blue
Poppy

Stormcloud

Stormcloud® is New Zealand’s most popular spouting style.

•  Versatile quarter-round profile
•  Clean, strong lines
•  Suits both traditional and contemporary homes
•  Available in a range of colours with matching RP80® downpipes

Typhoon

Typhoon® has been designed for high rainfall conditions.

•  Half-round profile. Excellent capacity and flow characteristics
•  Internal brackets for a smooth, contemporary look
•  Or external brackets for a retro design feature (also makes the inside of the spouting easier to clean)
•  Available in a range of colours with matching RP80® downpipes – including Metallics
